Data Sheet

Product Code:

MON-LCD-22VESA

Summary:

Reliable and essential for business efficiency, S Line54.61 cm (21.5") , 1920 x 1080, 250 cd/m², 16.7 M, DVI-D, VGA, HDMI, 100-240 V

SmartImage presets for easy optimized image settings
SmartImage is an exclusive leading edge Philips technology that analyzes the content displayed on your screen and gives you optimized display performance. This user friendly interface allows you to select various modes like Office, Photo, Movie, Game, Economy etc., to fit the application in use. Based on the selection, SmartImage dynamically optimizes the contrast, color saturation and sharpness of images and videos for ultimate display performance. The Economy mode option offers you major power savings. All in real time with the press of a single button!

16:9 Full HD display for crisp detailed images
Picture quality matters. Regular displays deliver quality, but you expect more. This display features enhanced Full HD 1920 x 1080 resolution. With Full HD for crisp detail paired with high brightness, incredible contrast and realistic colors expect a true to life picture.

LowBlue Mode for easy on-the-eyes productivity
Studies have shown that just as ultra-violet rays can cause eye damage, shortwave length blue light rays from LED displays can cause eye damage and affect vision over time. Developed for wellbeing, Philips LowBlue Mode setting uses a smart software technology to reduce harmful shortwave blue light.

Less eye fatigue with Flicker-free technology
Due to the way brightness is controlled on LED-backlit screens, some users experience flicker on their screen which causes eye fatigue. Philips Flicker-free Technology applies a new solution to regulate brightness and reduce flicker for more comfortable viewing.

HDMI ensures universal digital connectivity
An HDMI-ready device has all the required hardware to accept High-Definition Multimedia Interface (HDMI) input. A HDMI cable enables high-quality digital video and audio all transmitted over a single cable from a PC or any number of AV sources (including set-top boxes, DVD players, A/V receivers and video cameras).



Picture/Display
LCD panel type TFT-LCD (TN)
Backlight type W-LED system
Panel Size 21.5 inch / 54.6 cm
Display Screen Coating Anti-Glare, 3H, Haze 25%
Effective viewing area 476.64 (H) x 268.11 (V)
Aspect ratio 16:9
Optimum resolution 1920 x 1080 @ 60Hz
Pixel Density 102 PPI
Response time (typical) 1 ms (Gray to Gray)*
Brightness 250 cd/m²
Contrast ratio (typical) 1000:1
SmartContrast 20,000,000:1
Pixel pitch 0.248 x 0.248 mm
Viewing angle 170º (H) / 160º (V), @ C/R > 10
Flicker-free Yes
Picture enhancement SmartImage
Display colors 16.7 M
Color gamut (typical) NTSC 72% (CIE1931)
Scanning Frequency Horizontal: 30 - 83 kHz (Analog); 30 - 85 kHz (HDMI, Adaptive Sync for HDMI) / Vertical: 50 - 76 Hz (Analog, Digital); 48 - 76 Hz (HDMI, Adaptive Sync for HDMI)
sRGB Yes
EasyRead Yes
LowBlue Mode Yes
Adaptive sync Yes
Stand
Tilt -5/25  degree
Power
ECO mode 9.1 W (typ.)
On mode 14.2 W (typ.) (EnergyStar 7.0 test method)
Standby mode < 0.3 W (typ.)
Off mode < 0.3 W (typ.)
Power LED indicator Operation - White, Standby mode- White (blinking)
Power supply Built-in, 100-240VAC, 50-60Hz
Weight
Product with stand (kg) 2.80 kg
Product with stand (lb) 6.16 lb
Product without stand (kg) 2.46 kg
Product without stand (lb) 5.41 lb
Product with packaging (kg) 4.41 kg
Product with packaging (lb) 9.70 lb
Sustainability
Environmental and energy EnergyStar 7.0, EPEAT Gold*, TCO certified, RoHS, WEEE
Recyclable packaging material 100 %
Post consumer recycled plastic 25%
Specific Substances PVC / BFR free housing, Mercury free, Lead free
Cabinet
Front bezel Black/Black
Rear cover Black/Black
Foot Black/Black
Finish Texture
Connectivity
Signal Input DVI-D (digital, HDCP), VGA (Analog ), HDMI 1.4
Sync Input Separate Sync, Sync on Green
Audio (In/Out) Audio out
Convenience
User convenience SmartImage, Input, Brightness, Menu, Power On/Off
Control software SmartControl
OSD Languages Brazil Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukranian
Other convenience Kensington lock, VESA mount (100x100mm)
Plug & Play Compatibility DDC/CI, Mac OS X, sRGB, Windows 10 / 8.1 / 8 / 7
Dimensions
Product with stand(max height) 504 x 395 x 208 mm
Product with stand(max height) 19.8 x 15.6 x 8.2 inch
Product without stand (mm) 504 x 304 x 47 mm
Product without stand in inch 19.8 x 12.0 x 1.9 inch
Packaging in mm (WxHxD) 560 x 452 x 138 mm
Packaging in inch (WxHxD) 22.0 x 17.8 x 5.4 inch
Operating conditions
Temperature range (operation) 0°C to 40°C °C
Temperature range (storage) -20°C to 60°C °C
Relative humidity 20%-80 %
Altitude Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
MTBF (demonstrated) 70,000 hrs (excluded backlight)
Compliance and standards
Regulatory Approvals CE Mark, FCC Class B, SEMKO, cETLus, CU-EAC, TUV Ergo, TUV/GS, EPA, PSB, UKRAINIAN, ICES-003, BSMI, CEL, MEPS, TUV/ISO9241-307, VCCI
What's in the box?
Monitor with stand Yes
Cables D-Sub cable, HDMI cable, Power cable
User Documentation Yes
