4K HDMI Extender, Support 4K/1080p/720p over CAT5/6/7 Cable, 4K (w/CAT6)up to 40m, 1080p (w/CAT6) up to 70m with IR and PoE
Data Sheet
Product Code:
Product Code:
ADP-HDMI-EXT4K-70M
Summary:HDMI extender uses single network cable extender transmits HDMI signal up to 70meters over cat6 fluently and clearly. It is lossless in signal and supports 3D, 24bits deep color, 4Kx2K, CEC and HDCP. High quality transparent transmission, no compression, no delay, no signal loss. It supports LPCM, DTS Digital, and Dolby Digital audio transparent pass through. The transmission distance is up to is up to 70m at resolution up to 1080P@60Hz 36bpp by CAT6A/7 cable and 60m by CAT5E/5 cable; at resolution up to 4Kx2K 30Hz the distance is up to 40m by CAT6A/7 cable and 35m by CAT5E/CAT6. *Important note: the cable used should follow the standard of IEEE-568B, otherwise, the extender may be damaged With PoE. It only needs to input 12V power for either transmitter or receiver for normal working It supports a wide-band 20~60kHz bi-directional IR pass back. Users can control DVD at TX end and control TV at RX end.
-Apply transparent extend technology and transmit uncompressed HDMI audio video signal, and supports HDCP ,CEC, 24 deep color and uncompressed LPCM audio and compressed DTS-HD, Dolby True HD
-Support 480i/480P/576i/576P/720P/
- The transmission distance is up to is up to 70m at resolution up to 1080P@60Hz 36bpp by CAT6A/7 cable and 60m by CAT5E/6 cable; at resolution up to 4Kx2K 30Hz the distance is up to 40m by CAT6A/7 cable and 35m by CAT5E/CAT6.
-Can be powered by network cable. It only needs to input 12V power for either transmitter or receiver for normal working.
-Infrared back Support 20~60kHz wide frequency devices and Bi-directional IR transmission
-Power consumption: 8W
-Product dimension: 98.5(L)x66.5(W)x23(H)mm *2pcs
-Enclosure material : Metal
-Weight TX:79g RX:107g
-Color black
Package contents
Sender*1pcs
Receiver*1pcs
DC12V/2A *1pcs
IR blaster extension cable*1pcs
IR receiver extension cable*1pcs
User manual*1pcs
