Data Sheet

Code du produit:

GX-WCTS-MM4A-1600H

Résumé:

Add your own electronics, Built-in power system, Sound-attenuated diesel power backup, Rugged trailer built for integrators, Deluxe remote power management system

Trailer: Tubular steel welded construction, four 2,000 lb. stabilizer corner jacks for added wind stability, front access fork lift pockets, crane lifting eyes, round full wheel fenders that are bolted to the trailer frame, axle assembly 3,500 lb., double-eye leaf springs, 15” wheels / tires, red and white conspicuity tape

Drawbar: Tilting, 2” ball hitch, swivel wheel tongue jack, flat-four trailer lights plug

Tower: 24 -foot telescoping tower rotating 355 degrees, hand-operated winch for raising and lowering tower Camera mount: Multi-head camera box: 4x pendant arms (1-1/2” NPT), 5X Cat5E cable, 1X 16/2 power Control Box: Aluminum control box with 3-point locking door (24”W x 25”H x 10”D), solar / battery power

management meter, master battery/solar disconnect switch, power inverter 375W, Solar panel tilt switch, battery

protect, Cerbo GX communications mode

Solar: High-efficiency photovoltaic solar modules, capacity 1,600-Watts, dual electric actuator-tilt, Smart MPPT blue- tooth solar controller, battery “state of charge and time-remaining” feature

Hybrid diesel option: Sound attenuated / fluid containment air cooled auto start/stop diesel engine package, Flywheel-integrated permanent magnet 100A electronic charging, 22-gallon fuel tank

Batteries: Single Wanco battery box with bolted lid, four 12V sealed AGM batteries (400 Ah @24Vdc total capacity), 50 Amp battery charger

Standard color: Powder coated flat black trailer frame and mast, white battery box and NEMA box
