Video and Audio

IP Video Input

8-ch

Incoming Bandwidth

80 Mbps

Outgoing Bandwidth

80 Mbps

Decoding

Decoding Format

H.265, H.265+, H.264, H.264+

Decoding Capability

8-ch@1080p (30 fps)

*: The total resolution of all cloud storage video channels cannot exceed 8 × 1080p (30 fps).

Stream Type

Video, Video & Audio

Encoding

Video Encoding Resolution

1080p/720p

Encoding Capability

2-ch@1080p (30 fps)

Frame Rate

5-ch@1080p (10 fps), 6-ch@1080p (8 fps), 7-ch@1080p (7 fps), 8-ch@1080p (6 fps)

*: 5-ch/6-ch/7-ch/8-ch is the total number of channels for uploading cloud storage videos.

Network

Network Protocol

IPv4, IPv6, HTTP, HTTPS, NTP, SADP, DHCP

Network Interface

1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

General

Power output

12 VDC, 1A

Consumption

</= 6 W

Working Temperature

-10 °C to 55 °C (14 °F to 131 °F)

Working Humidity

10? to 90?

Dimension (W × D × H)

92 × 93 × 45.8 mm (3.6 × 3.7 × 1.8 inch)

Weight

</= 0.5 kg (1.1 lb)
